Setting up [Label Data]

Set up the "Label data" with the following steps.

Note

Operations of the ProcItem Setting window

For the basic operations of the ProcItem Setting window, see User's Manual, "Operations of ProcItem Setting Window".

Tap [Label data] in the Edit Flow window.
The ProcItem Setting window is displayed.
User's Manual, "ProcItem Setting Window"
In the "Item tab" area, tap [Setting] to specify the label conditions used for measurement and the judgement conditions to be judges as OK.
[Setting (Label Data)]
Tap [OK].
After confirmation, the ProcItem Setting window will be closed.
Perform a measurement test.
User's Manual, "Test Measurement before Actual Operation"
Verify measurement results.
User's Manual, "Display of the RUN Window"
When NG is displayed, please verify measurement results and make adjustment if necessary.
Points on Measurement Test and Adjustment (Label Data)
