3D Edge Position

This processing item is for 3D measurement only.
This processing item measures the edge position X/Y/Z by stereo measurement.

3D Edge Position items are explained below.

Table: List of 3D Edge Position Items
Item Name	Description
Region setting	This item specifies the region to be measured. [Region Setting (3D Edge Position)]
Edge color specification (for color cameras only)	This item specifies an edge color information to be detected. [Edge Color - For Color Cameras Only (3D Edge Position)]
Ref.position	This item can be changed if necessary. [Ref. Position (3D Edge Position)]
Measurement	This item specifies the judgement condition for measurement results. Measurement values can be changed as needed to address unstable measurement results. The displayed items are different depending on whether your system is a color or monochrome camera. Usually, the factory default value can be used. [Measurement (3D Edge Position)]
Output parameter	This item can be changed if necessary. Usually, the factory default value can be used. Use the Output parameter to specify how to treat the coordinates. [Output Parameter (3D Edge Position)]
